Talon 1

$1,000

Similar Products

Best For: XC

Talon 2

$800

Best For: XC

Talon 4

$650

The mountain bike experience starts here. With a redesigned frame that’s now lighter and more durable, along with a smooth-riding suspension fork, thru-axle hubs*, and a 1x drivetrain*, this aluminum hardtail is everything an aspiring MTB rider needs to evolve and advance. *on select models

Key Performance Factors

Modern MTB Design

Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models

Off-Road Control

New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.

Light and Durable

All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.

Highlights

The mountain bike experience starts here. With a redesigned frame that’s now lighter and more durable, along with a smooth-riding suspension fork, thru-axle hubs*, and a 1x drivetrain*, this aluminum hardtail is everything an aspiring MTB rider needs to evolve and advance.

Talon with interactive tooltips

Techs & Features

ALUXX Aluminum Technology

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XS (27.5")
      155 cm5’1”  to 166 cm5’5”
  • S (29")
      163 cm5’4”  to 172 cm5’8”
  • M (29")
      169 cm5’7”  to 179 cm5’10”
  • L (29")
      176 cm5’9”  to 186 cm6’1”
  • XL (29")
      183 cm6’0”  to 193 cm6’4”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  XS (27.5")S (29")M (29")L (29")XL (29")
ASeat Tube Length (mm) (inch)34513.63801542016.545017.748018.9
A1Seat Post Insertion Depth (mm) (inch)3061234013.42007.92379.329211.5
BSeat Tube Angle (degrees)74.0°74.5°74.5°74.5°74.5°
CTop Tube Length (mm) (inch)54221.358122.960423.862924.865325.7
DHead Tube Length (mm) (inch)903.5953.71054.11254.91405.5
EHead Tube Angle (degrees)67.0°67.5°67.5°67.5°67.5°
FFork Rake (mm) (inch)441.7441.7441.7441.7441.7
GTrail (mm) (inch)105.24.1108.94.3108.94.3108.94.3108.94.3
HWheelbase (mm) (inch)108442.7113944.8116445.8119146.9121747.9
IChain Stay Length (mm) (inch)44017.345517.945517.945517.945517.9
JBottom Bracket Drop (mm) (inch)451.8552.2552.2552.2552.2
KStack (mm) (inch)54821.659723.560623.962524.663925.2
LReach (mm) (inch)38515.241516.343617.24561847618.7
MStand Over Height (mm) (inch)68426.971528.170927.970927.971028
NHandlebar Width (mm) (inch)69027.269027.269027.269027.269027.2
OStem Length (mm) (inch)401.6502602.4702.8803.1
PCrank Length (mm) (inch)1656.51706.71706.71706.71756.9
QWheel Size 27.5"29"29"29"29"
Specs
  • Sizes
    27.5: XS,S, 29: S,M,L,XL,XXL
  • Colors
    Metallic Blue, Charcoal
  • Frame
    ALUXX-grade aluminum, disc
  • Fork
    SXC32-3 RL, coil spring, thru axle, steel steerer, 15x110 XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M:100mm travel (29) L: 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29)
  • Shock
    N/A
  • Handlebar
    Giant Connect Trail, 31.8mm XS: 690mm (27.5) S: 690mm (27.5) / 750mm (29) M: 780mm (29) L: 780mm (29) XL: 780mm (29) XXL: 780mm (29)
  • Grips
    Giant Sole-O
  • Stem
    Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (29) L: 70mm (29) XL: 80mm (29) XXL: 90mm (29)
  • Seatpost
    Giant Contact Switch Core, 30.9 XS: 100x350mm (27.5) S: 100x350mm (27.5) / 100x350mm (29) M: 120x400mm (29) L: 120x400mm (29) XL: 120x400mm (29) XXL: 120x400mm (29)
  • Saddle
    Giant ErgoContact Trail
  • Pedals
    MTB caged
  • Shifters
    Shimano CUES SL-6000, 1x10
  • Front Derailleur
    N/A
  • Rear Derailleur
    Shimano CUES RD-U6000, clutch
  • Brakes
    Tektro HDC M275, hydraulic, Tektro rotors [F]180mm, [R]160mm
  • Brake Levers
    Tektro HDC M275
  • Cassette
    Shimano CUES, CS-LG300, 11x48
  • Chain
    KMC X-11
  • Crankset
    ProWheel Charm, 32t (27.5) or 30t (29) XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (29) L: 170mm (29) XL: 175mm (29) XXL: 175mm (29)
  • Bottom Bracket
    cartridge
  • Rims
    Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
  • Hubs
    [F] Giant Tracker hub, sealed bearing, 15x110 thru axle. [R] Giant Tracker hub, 12x142 thru axle, 24-pawl drive
  • Spokes
    stainless, 14g
  • Tires
    Maxxis Rekon 27.5x2.4" or Maxxis Rekon Race 29x2.4", wire bead
  • Extras
    2.4" max tire size
  • Weight
    14.59 kg (32 lbs 03 oz) - Size (L)

*All specifications and prices listed are subject to change without notice.
Actual weight may vary due to manufacturing tolerances, color variations, frame size and variability in production components.
