FastRoad AR Advanced 2

$1,800

Techs & Features

Advanced Composite Technology
Tubeless System

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • S
      160 cm5’3”  to 170 cm5’7”
  • M
      170 cm5’7”  to 180 cm5’11”
  • ML
      175 cm5’9”  to 185 cm6’1”
  • L
      180 cm5’11”  to 190 cm6’3”
  • XL
      190 cm6’3”  to 200 cm6’7”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  SMMLLXL
ASeat Tube Length (mm) (inch)45517.947518.749519.552520.755521.9
BSeat Tube Angle (degrees)73.5°73.5°73.0°73.0°73.0°
CTop Tube Length (mm) (inch)5602257522.659023.26102463024.8
DHead Tube Length (mm) (inch)1305.11556.11756.92007.92258.9
EHead Tube Angle (degrees)70.5°71.0°71.0°71.5°71.5°
FFork Rake (mm) (inch)502502502502502
GTrail (mm) (inch)73.72.970.42.870.42.867.12.667.12.6
HWheelbase (mm) (inch)104741.2105841.7106942.1108442.7110543.5
IChain Stay Length (mm) (inch)43517.143517.143517.143517.143517.1
JBottom Bracket Drop (mm) (inch)753753753753753
KStack (mm) (inch)55221.757822.859723.562324.564625.4
LReach (mm) (inch)39615.640415.94071641916.543217
MStand Over Height (mm) (inch)7362975629.877330.480031.582632.5
NHandlebar Width (mm) (inch)64025.268026.868026.868026.868026.8
OStem Length (mm) (inch)803.1903.5903.51003.91104.3
PCrank Length (mm) (inch)1706.71706.7172.56.8172.56.8172.56.8
QWheel Size 700C700C700C700C700C
Specs
  • Sizes
    XS, S, M, M/L, L, XL
  • Colors
    Tiger Red
  • Frame
    Advanced-grade composite, 12x142mm thru-axle, disc
  • Fork
    Advanced-grade composite, composite OverDrive steerer, 12x100mm thru-axle, disc
  • Shock
    N/A
  • Handlebar
    Giant Sport Flat, 31.8 XS:64cm, S:64cm, M:68cm, M/L: 68cm, L:68cm, XL:68cm
  • Grips
    Giant ErgoContact
  • Stem
    Giant Contact, 8-degree XS:70mm, S:80mm, M:90mm, M/L: 90mm, L:100mm, XL:110mm
  • Seatpost
    Giant D-Fuse, alloy, 350mm
  • Saddle
    Giant ErgoContact
  • Pedals
    platform pedal [GCS,GTS, GU, GV] N/A [all other GSC]
  • Shifters
    Shimano CUES U6000, 10-speed
  • Front Derailleur
    N/A
  • Rear Derailleur
    Shimano CUES
  • Brakes
    Tektro HD-R280, Giant MPH rotors [F]160mm, [R]160mm
  • Brake Levers
    Tektro HD-R280
  • Cassette
    Shimano CS-LG40010, 11x48
  • Chain
    Shimano CN-LG500
  • Crankset
    FSA Omega AGX+, 42t XS:170mm, S:170mm, M:170mm, M/L:172.5mm, L:172.5mm, XL: 175mm
  • Bottom Bracket
    FSA, press fit
  • Rims
    Giant S-X2 Disc wheelset
  • Hubs
    Giant alloy, 12mm thru-axle
  • Spokes
    Sapim
  • Tires
    Maxxis Re-Fuse, tubeless, 700x40c
  • Extras
    tubeless prepared, 42mm max tire size
  • Weight
    9.73kg (21lb 08oz) - Size (S)

*All specifications and prices listed are subject to change without notice.
Actual weight may vary due to manufacturing tolerances, color variations, frame size and variability in production components.
