Best For: Dirt Jumper
STP 20
749 €
State-of-the-art aluminum material delivers best-in-class strength-to-weight ratios. The frameset also features unique welding technologies for a performance ride quality.
Nové
This is an image carousel with thumbnail navigation. Select any thumbnail to view an enlarged version in a gallery modal. In the gallery, use the Next and Previous buttons to navigate between images, or close the modal to return to the thumbnails.
STP 20 FS
699 €
Podobné produkty
Dirt skills start here. With a lightweight aluminum frame that has a low stand-over height, a smooth-riding composite fork, and 20-inch wheels, the new STP 20 gives kids the confidence and maneuverability they need to start leaning into the turns, shifting their weight, and popping some air. It’s all the things that make riding fun.
Hlavné výhody
FIT FOR YOUTH
The frame’s low stand-over height offers greater balance and stability with a lower center of gravity that’s ideal for riders 110-130cm tall. The 20-inch wheels and shorter 105mm cranks make for easier handling and smoother pedaling.
GREATER CONTROL
Youth-specific components including a Grit Core Lite saddle, smaller diameter handlebars, and hydraulic brakes with lighter modulation give STP 20 a smooth, controlled ride, helping young riders focus on building skills and gaining confidence.
PLAYFUL AGILITY
With a lightweight, durable ALUXX aluminum frame and Advanced-grade composite fork, the STP 20 is easy for young riders to maneuver. A shorter wheelbase and chainstays add a playful feel and make it easier to lift the front wheel while riding.
Výhody
1
ALUXX ALUMINUM
2
COMPOSITE FORK*
Lightweight Advanced-grade composite fork absorbs road shock and vibrations, delivering a smoother ride quality and pinpoint steering precision.
3
SUSPENSION FORK*
The STP 20 FS model features a SR Suntour XCT Jr. 63mm suspension fork for a more trail oriented feel.
4
20-INCH WHEELS
Smaller diameter wheels featuring Giant TRA rims with Wide Guard technology are optimized for the frame geometry. Minimal weight and rugged durability make them ideal for young dirt riders.
5
GRIPPY TIRES
Large, high-volume tubeless tires offer maximum grip and a smooth, controlled ride on dirt and other surfaces.
6
YOUTH-OPTIMIZED SHIFTERS
MicroShift 1x8 Acolyte levers offer intuitive controls—the index finger for a harder gear, the thumb for an easier gear—and a clear gear indicator to make shifting simple.
7
YOUTH-OPTIMIZED BRAKES
Hydraulic brakes with shorter travel brake levers are tuned with lighter modulation compared to adult brakes. This results in greater control and traction on dirt tracks and trails.
8
YOUTH-OPTIMIZED DRIVETRAIN
A 1x8 drivetrain featuring shorter 105mm cranks, a 30-tooth chainring, and a wide 11-38 gear range helps young riders conquer hilly terrain with optimal pedaling cadence.
9
GIANT GRIT CORE LITE SADDLE
A narrow 125mm saddle width delivers optimal positioning and fit to help young riders tackle longer rides with greater comfort.
10
INTERNAL CABLE ROUTING
Derailleur, brake and dropper post cables are routed internally through integrated ports, saving weight while creating a cleaner look and better performance.
Technológie
ALUXX hliníková technológia
Tento rámový materiál na vysokej úrovni obsahuje zliatinu 6061 s jednoduchými zosilnenými rúrkami, ktoré vytvárajú silné a ľahké rámové sady pre rôzne bicykle a jazdné štýly.
Výber veľkosti a geometrie
Uvedené hodnoty sú orientačné. Odporúčame výber veľkosti konzultovať u vášho autorizovaného predajcu Giant / Liv a veľkosť rámu si pred nákupom bicykla vyskúšať.
- One Size
- 110 cm3’7”
130 cm4’3”
| One Size | |
|---|---|
| A Dĺžka sedlovej trubky (mm) (inch) | 26510,4 |
| A1 Hĺbka vloženia sedlovky (mm) (inch) | 2007,9 |
| B Uhol sedlovej trubky (degrees) | 73,0° |
| C Dĺžka hornej rámovej trubky (mm) (inch) | 44417,5 |
| D Dĺžka hlavovej trubky (mm) (inch) | 903,5 |
| E Uhol hlavovej trubky (degrees) | 67,0° |
| F Offset vidlice (mm) (inch) | 401,6 |
| G Trail (mm) (inch) | 913,6 |
| H Rázvor (mm) (inch) | 82132,3 |
| I Dĺžka zadnej stavby (mm) (inch) | 32312,7 |
| J Rozdiel zadnej voči stredovej osi - BB DROP (mm) (inch) | 502 |
| K Stack - výška riadenia (mm) (inch) | 44717,6 |
| L Reach (mm) (inch) | 30111,9 |
| M Výška rámu od zeme (mm) (inch) | 53621,1 |
| N Šírka riaditok (mm) (inch) | 60023,6 |
| O Dĺžka predstavca (mm) (inch) | 401,6 |
| P Dĺžka kľúk (mm) (inch) | 1054,1 |
Všetky ceny a špecifikácie sa môžu zmeniť bez predchádzajúceho upozornenia.
