Propel Advanced SL
Disc Frameset
Highlights
The Propel Advanced SL Disc is engineered with Giant’s AeroSystem Shaping technology, which means every tube shape and angle is optimized for minimal drag. The tubes feature a truncated ellipse shape for a frame that is ultra-stiff and superlight. Disc-brake technology is integrated into the frameset with flat-mount calipers and thru-axles for optimal wheel stiffness and braking performance.
Techs & Features
Advanced SL Composite Technology
Professional Grade raw carbon fiber is woven in our composite factory to produce our lightest, stiffest and highest quality frames. This is the technology used by Giant’s pro racers in almost every cycling discipline.
AeroSystem Shaping Technology
Through CFD (Computational Fluid Dynamics) and wind-tunnel data, engineers optimize each tube shape to deliver superior aerodynamic performance.
Integrated Seatpost
Designed as a key performance factor in the overall frameset, the integrated seatpost saves up to 45 grams compared to standard composite posts, while improving aerodynamics and adding road-smoothing compliance.
OverDrive 2
The most advanced steerer tube technology in today’s Giant bikes. Designed to offer unprecedented front-end steering performance, the system’s oversized headset bearings (1 1/2” lower, 1 1/4” upper) and tapered steerer tube work in harmony to provide supreme steering stiffness.
RideSense Ready
This frame comes prepared to accept the Giant RideSense sensor and accompanying hardware.
Sizing Guide and Geometry
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
- XS
- 157 cm5’2”
169 cm5’7”
- S
- 165 cm5’5” 175 cm5’9”
- M
- 171 cm5’7” 181 cm5’11”
- ML
- 177 cm5’10” 187 cm6’2”
- L
- 183 cm6’0” 193 cm6’4”
- XL
- 189 cm6’2” 199 cm6’6”
| XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 68026,8 | 71028 | 74029,1 | 77030,3 | 79031,1 | 82032,3 |
| B | Seat Tube Angle (degrees) | 74,5° | 73,5° | 73,0° | 73,0° | 73,0° | 72,0° |
| C | Top Tube Length (mm) (inch) | 51520,3 | 53521,1 | 55021,7 | 57022,4 | 58022,8 | 60523,8 |
| D | Head Tube Length (mm) (inch) | 1204,7 | 1305,1 | 1455,7 | 1656,5 | 1857,3 | 2007,9 |
| E | Head Tube Angle (degrees) | 71,0° | 72,5° | 73,0° | 73,0° | 73,0° | 73,0° |
| F | Fork Rake (mm) (inch) | 451,8 | 451,8 | 451,8 | 451,8 | 451,8 | 451,8 |
| G | Trail (mm) (inch) | 702,8 | 602,4 | 572,2 | 572,2 | 572,2 | 572,2 |
| H | Wheelbase (mm) (inch) | 97238,3 | 97038,2 | 97638,4 | 99739,3 | 100739,6 | 102140,2 |
| I | Chain Stay Length (mm) (inch) | 40515,9 | 40515,9 | 40515,9 | 40515,9 | 40515,9 | 40515,9 |
| J | Bottom Bracket Drop (mm) (inch) | 702,8 | 682,7 | 682,7 | 652,6 | 652,6 | 652,6 |
| K | Stack (mm) (inch) | 51720,4 | 52920,8 | 54521,5 | 56222,1 | 58122,9 | 59523,4 |
| L | Reach (mm) (inch) | 37214,6 | 37814,9 | 38315,1 | 39815,7 | 40215,8 | 41216,2 |
| M | Stand Over Height (mm) (inch) | 74429,3 | 76930,3 | 78731 | 80731,8 | 82932,6 | 84333,2 |
| N | Handlebar Width (mm) (inch) | 40015,7 | 40015,7 | 42016,5 | 42016,5 | 44017,3 | 44017,3 |
| O | Stem Length (mm) (inch) | 803,1 | 903,5 | 1003,9 | 1104,3 | 1104,3 | 1204,7 |
| P | Crank Length (mm) (inch) | 1706,7 | 1706,7 | 172,56,8 | 172,56,8 | 1756,9 | 1756,9 |
| Q | Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
All specifications listed are subject to change without notice.
