Chill 1 GTS

2020

What is my size?

Share

Specs
MarimiGTS: M, L, XL
CuloriWarm Grey
CadruALUXX-Grade Aluminium
FurcaVast, aluminium ; Unifork 075
GhidonGiant City aluminium
PipaAluminium vast
Tija saRigid SP130 Double bolt
SaSelle Royal Wave
PedaleCity platform
Manete schimbatorShimano Nexus 7; SL-7S31
Schimbator fatan/a
Schimbator spaten/a
FraneShimano Rollerbrakes BR-IM31-R (EC) achter, BR-C3000-F voor
Manete franaTektro CL330-RS-AC
Pinioane18T
LantKMC Z610X
AngrenajGiant, 38T
Bottom BracketBOOGIE 3.0
JanteMach 1 810
ButuciShimano Naafdynamo DH-C6000-1R / Shimano Nexus 7
SpiteSapim
AnvelopeCST Reach 37-622
LightingVoor: Spanninga Galeo XDO / Achter: Marwi UN4450
LockAXA Solid XL
Greutate18,6 kg

Toate specificatiile enumerate se pot schimba fara notificare prealabila.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.

  • Medium
      170 cm5’7”  to 180 cm5’11”
  • Large
      180 cm5’11”  to 190 cm6’3”
  • X-Large
      190 cm6’3”  to 200 cm6’7”
bike diagram
  MediumLargeX-Large
Seat Tube Angle (degrees)72,5°72,5°72,5°
Top Tube Length (mm) (inch)560225852360023,6
Head Tube Length (mm) (inch)1606,31606,31907,5
Head Tube Angle (degrees)70,0°70,0°70,0°
Wheelbase (mm) (inch)109743,2111744113944,8
Chain Stay Length (mm) (inch)46018,146018,146018,1
