Trance 29 1

3 149 €

¿Cuál es mi talla?

Share

Turn up the heat on technical trails, and do it with more confidence and control. Featuring updated suspension and adjustable geometry, this feisty 29er adapts to the terrain.

Key Performance Factors

Adjustable frame geometry

New flip chip feature lets you change the head tube and seat tube angles, as well as the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style.

29er confidence and control

Larger 29-inch diameter wheels optimized to roll over rough terrain with balance and stability, giving you the momentum to tackle technical climbs and the confidence to fly on fast, rugged singletrack descents.

Progressive trail design

Lightweight ALUXX SL aluminum frameset features a longer reach and steeper seat tube for aggressive trail riding and improved climbing capabilities. Updated Maestro rear suspension features 120mm of rear wheel travel paired with a 130mm fork up front.

Highlights

This versatile trail machine is built on a lightweight, stiff and super-strong ALUXX SL frameset that blends our latest Maestro suspension technology with adjustable frame geometry. The Advanced Forged Composite rocker arm has a flip chip that allows you to adjust frame geometry. Choose steeper or slacker head tube/seat tube angles and either a 35mm or 45mm bottom bracket drop to fine-tune the handling for your riding style and terrain. It’s designed around a 130mm travel suspension fork, and the overall geometry has been tuned to maximize its performance on rugged trails.

Trance 29 with interactive tooltips

Techs & Features

Advanced Forged Composite Technology
ALUXX SL Aluminum Technology
Maestro Suspension Technology
OverDrive
Tubeless System
Flip Chip - Maestro

Guia de dimensionamento e geometria

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • S
      163 cm5’4”  to 172 cm5’8”
  • M
      171 cm5’7”  to 180 cm5’11”
  • L
      179 cm5’10”  to 188 cm6’2”
  • XL
      187 cm6’2”  to 198 cm6’6”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  SMLXL
  LOW | HIGHLOW | HIGHLOW | HIGHLOW | HIGH
AComprimento do tubo do assento (mm) (inch)42016,543016,946518,349619,5
BÂngulo do tubo do assento (degrees)77,2° | 78,0°76,3° | 77,0°76,3° | 77,0°76,3° | 77,0°
CComprimento do tubo superior (mm) (inch)56122,1 | 5592259923,6 | 59723,562624,6 | 62424,666326,1 | 66126
DComprimento do tubo principal (mm) (inch)1003,91104,31204,71305,1
EÂngulo do tubo principal (degrees)65,4° | 66,2°65,5° | 66,2°65,5° | 66,2°65,5° | 66,2°
FGarfo ancinho (mm) (inch)441,7441,7441,7441,7
GTrilha (mm) (inch)1265 | 1204,71265 | 1204,71265 | 1204,71265 | 1204,7
Hdistância entre eixos (mm) (inch)116645,9 | 116545,9119547 | 119447122448,2 | 122348,1126349,7 | 126249,7
IComprimento Chain Stay (mm) (inch)43917,3 | 43717,243917,3 | 43717,243917,3 | 43717,243917,3 | 43717,2
JSuporte inferior (mm) (inch)451,8 | 351,4451,8 | 351,4451,8 | 351,4451,8 | 351,4
KPilha (mm) (inch)61024 | 60423,861924,4 | 61324,162824,7 | 62224,563725,1 | 63124,8
LAlcançar (mm) (inch)42216,6 | 4311744717,6 | 4561847218,6 | 48018,950720 | 51520,3
MAltura do standover (mm) (inch)73028,7 | 73829,172528,5 | 73428,974929,5 | 75929,977130,4 | 78030,7
NLargura do guidão (mm) (inch)78030,778030,778030,778030,7
OComprimento da haste (mm) (inch)401,6401,6502502
PComprimento da Manivela (mm) (inch)1656,51706,71706,71706,7
QTamanho da roda 29"29"29"29"
Specs
  • Tamanhos
    S, M, L, XL
  • Cores
    Phantom Green / Black / Chrome
  • Quadro
    ALUXX SL-Grade Aluminum front and rear triangles, 120mm Maestro suspension, flip chip, 12x148mm thru-axle
  • Forquilha
    Fox 34 Performance, 130mm, GRIP damper, Boost 15x110 Kabolt, 44mm offset, custom tuned for Giant
  • Amortecedores
    Fox Float DPS Performance, 185/50, custom tuned for Giant
  • Guiador
    Giant Contact TR35, 780x35mm
  • Punhos
    Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm
  • Avanço
    Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
  • Espigão de selim
    Giant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm M: 150mm travel / 30.9 x 440mm L: 170mm travel / 30.9 x 450mm XL: 170mm travel / 30.9 x 450mm
  • Selim
    Giant Romero
  • Pedais
    N/A
  • Manetes
    Shimano SLX SL-M7100, 1x12
  • Desviador dianteiro
    N/A
  • Desviador traseiro
    Shimano SLX RD-M7100
  • Travões
    Shimano Deore BR-MT520, hydraulic, Shimano RT-56 rotors [F]180mm, [R]180mm
  • Manípulos dos travões
    Shimano BL-MT501
  • Cassete
    Shimano SLX, 10x51
  • Corrente
    KMC X-12
  • Conjunto pedaleiro
    Shimano SLX, 30t S:165mm, M:170mm, L:170mm, XL:170mm
  • Movimento Central
    Shimano, press fit
  • Aros
    Giant AM 29 tubeless ready sleeve-joint rim, 30mm inner width
  • Cubos
    alloy, sealed
  • Raios
    Sapim
  • Pneus
    [F] Maxxis Minion DHF 29x2.5 WT, 3C MaxxTerra, EXO, TR [R] Maxxis Aggressor 29x2.5, EXO, TR, tubeless
  • Extras
    tubeless prepared, 2.6" max tire size, 34t max chainring size
  • Peso
    Quanto pesa esta bicicleta? Esta é uma pergunta comum e importante. Mas a verdade é que não existem normas da indústria que permitam comparar o peso de uma bicicleta entre marcas o que faz com que haja muita informação errada. Existem diferenças em termos de tamanho, material utilizado no quadro, acabamentos e peças. E à medida que as bicicletas se tornam mais leves, maiores são essas diferenças. Na Giant, acreditamos que a única maneira de se saber realmente o peso de uma bicicleta é informar-se no seu revendedor local.

Todas as especificações apresentadas estão sujeitas a alterações sem aviso prévio.
