Yukon 2

2020

Hva er min størrelse

Share
WHY FOLLOW TRACKS WHEN YOU CAN MAKE YOUR OWN? EXPERIENCE THE “FOOT OUT, FLAT OUT” FUN OF FAT BIKE RIDING IN ANY SEASON. WHETHER YOU’RE TACKLING FRESH SNOW PACK OR DRIFTY SAND DUNES FOR DAYS, THE NEW YUKON WILL KEEP YOU RALLYING YOUR FAVORITE TERRAIN IN A WHOLE NEW WAY.

Key Performance Factors

Low Center of Gravity Playful Trail Bike

Sloping "low slung" front triangle design provides a low center of gravity for technical maneuvering with ease or countersink control in deep conditions.

Maximum Heel Clearance with Low Q-Factor

With a heavily swaged rear triangle including dropouts, seatstays and chainstays, this versatile design allows even warmest of riding boots to be worn, while the narrow Q-Factor crank specification provides a more natural feeling cycling experience.

Custom Wheelbase Adjustment and Tire Size Flexibility

The horizontal adjustable drop out system allows for +/- 15mm rear center length adjustment and tire sizing up 27.5 X 4.5” for maximum floatation to and a fun, playful ride.

Specs
  • Størrelse
    S, M, L, XL
  • Farge
    Black / Charcoal, Gray White / Pure Red
  • Ramme
    ALUXX SL-Grade Aluminum with horizontal dropouts
  • Gaffel
    Rigid composite with alloy steerer, 15x150, with low rider rack mounts
  • Demper
    N/A
  • Styre
    Giant Connect Trail, 780x31.8
  • Styrstem
    Giant Contact
  • Setepinne
    Giant Connect, 30.9
  • Sadel
    Giant Contact (neutral)
  • Pedaler
    N/A
  • Girhendler
    Shimano Deore
  • Frontgir
    N/A
  • Bakgir
    Shimano Deore
  • Bremser
    Shimano MT200
  • Bremsehendler
    Shimano MT201
  • Kassett
    Shimano HG500, 11x42
  • Kjede
    Shimano
  • Krank
    Prowheel MPX, 28t Wave ring
  • Bottom Bracket
    Prowheel, press fit
  • Felg
    alloy, 27.5", 90mm
  • Nav
    [F] Giant 15x150 sealed bearing [R] Giant 12x197 sealed bearing
  • Eike
    stainless, 14g
  • Dekk
    Maxxis Colossus 27.5x4.5, foldable, TR,
  • Vekt
    Hvor mye veier denne sykkelen? Dette er et vanlig spørsmål, men sannheten er at det ikke finnes noen bransjestandard for å sette en vekt. Vi i Giant tror den eneste måten å virkelig finne vekten av en bestemt sykkel er å dra til din lokale forhandler.

Alle spesifikasjonene kan endres uten varsel.

Highlights

The incredible capability of the Yukon series will keep you conquering and grinning in all conditions. This feature-packed design offers a modern trail bike experience coupled with maximum control and floatation over the most ridiculous of surfaces. Its lightweight Aluxx SL-Grade frame tubeset and Advanced Composite grade fork featuring wide axle spacing (150/197mm [F/R] ) and a PressFit 121 bottom bracket, makes this modern fat bike agile and versatile. Its stabile and adjustable geometry, high volume 27.5”X 4.5” tire capability and ample clearances means you’ll never miss a day of riding again, no matter the season.

2020 Yukon with interactive tooltips

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • S
      163 cm5’4”  to 172 cm5’8”
  • M
      171 cm5’7”  to 180 cm5’11”
  • L
      179 cm5’10”  to 188 cm6’2”
  • XL
      187 cm6’2”  to 198 cm6’6”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  SMLXL
  LOW | HIGHLOW | HIGHLOW | HIGHLOW | HIGH
ASeat Tube Length (mm) (inch)38115432174831953321
BSeat Tube Angle (degrees)73,0°73,0°73,0°73,0°
CTop Tube Length (mm) (inch)5852360523,862524,664525,4
DHead Tube Length (mm) (inch)1003,91154,51305,11505,9
EHead Tube Angle (degrees)68,5°68,5°68,5°68,5°
FFork Rake (mm) (inch)602,4602,4602,4602,4
GTrail (mm) (inch)90,13,590,13,590,13,590,13,5
HWheelbase (mm) (inch)1128,644,41149,845,21171,146,11192,746,9
IChain Stay Length (mm) (inch)44517,5 | 46018,144517,5 | 46018,144517,5 | 46018,144517,5 | 46018,1
JBottom Bracket Drop (mm) (inch)753753753753
KStack (mm) (inch)621,524,4635,525649,425,666826,3
LReach (mm) (inch)39515,6410,716,1426,516,8440,817,3
MStand Over Height (mm) (inch)71928,373528,977230,481131,9
NHandlebar Width (mm) (inch)78030,778030,778030,778030,7
OStem Length (mm) (inch)502502602,4702,8
PCrank Length (mm) (inch)1706,71706,71756,91756,9
QWheel Size 27.527.527.527.5

Alle spesifikasjonene kan endres uten varsel.
