Propel Advanced SL Disc Frameset

Hva er min størrelse

Share

Highlights

The Propel Advanced SL Disc is engineered with Giant’s AeroSystem Shaping technology, which means every tube shape and angle is optimized for minimal drag. The tubes feature a truncated ellipse shape for a frame that is ultra-stiff and superlight. Disc-brake technology is integrated into the frameset with flat-mount calipers and thru-axles for optimal wheel stiffness and braking performance.

Propel Advanced SL Disc Frame with interactive tooltips

Techs & Features

Advanced SL Composite Technology
AeroSystem Shaping Technology
Integrated Seatpost
OverDrive 2
RideSense Ready

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XS
      157 cm5’2”  to 169 cm5’7”
  • S
      165 cm5’5”  to 175 cm5’9”
  • M
      171 cm5’7”  to 181 cm5’11”
  • ML
      177 cm5’10”  to 187 cm6’2”
  • L
      183 cm6’0”  to 193 cm6’4”
  • XL
      189 cm6’2”  to 199 cm6’6”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  XSSMMLLXL
ASeat Tube Length (mm) (inch)68026,87102874029,177030,379031,182032,3
BSeat Tube Angle (degrees)74,5°73,5°73,0°73,0°73,0°72,0°
CTop Tube Length (mm) (inch)51520,353521,155021,757022,458022,860523,8
DHead Tube Length (mm) (inch)1204,71305,11455,71656,51857,32007,9
EHead Tube Angle (degrees)71,0°72,5°73,0°73,0°73,0°73,0°
FFork Rake (mm) (inch)451,8451,8451,8451,8451,8451,8
GTrail (mm) (inch)702,8602,4572,2572,2572,2572,2
HWheelbase (mm) (inch)97238,397038,297638,499739,3100739,6102140,2
IChain Stay Length (mm) (inch)40515,940515,940515,940515,940515,940515,9
JBottom Bracket Drop (mm) (inch)702,8682,7682,7652,6652,6652,6
KStack (mm) (inch)51720,452920,854521,556222,158122,959523,4
LReach (mm) (inch)37214,637814,938315,139815,740215,841216,2
MStand Over Height (mm) (inch)74429,376930,37873180731,882932,684333,2
NHandlebar Width (mm) (inch)40015,740015,742016,542016,544017,344017,3
OStem Length (mm) (inch)803,1903,51003,91104,31104,31204,7
PCrank Length (mm) (inch)1706,71706,7172,56,8172,56,81756,91756,9
QWheel Size 700C700C700C700C700C700C
Specs
  • Størrelse
    XS, S, M, M/L, L, XL
  • Farge
    Carbon, Hematite
  • Ramme
    Advanced SL-Grade Composite, integrated seatpost, disc
  • Gaffel
    Advanced SL-Grade Composite, full-composite OverDrive 2 steerer, disc
  • Demper
    N/A
  • Setepinne
    Advanced SL-Grade composite, integrated design, -5/+15mm offset
  • Extras
    28mm max tire size, 12mm thru-axles
  • Vekt
    Hvor mye veier denne sykkelen? Dette er et vanlig spørsmål, men sannheten er at det ikke finnes noen bransjestandard for å sette en vekt. Vi i Giant tror den eneste måten å virkelig finne vekten av en bestemt sykkel er å dra til din lokale forhandler.

Alle spesifikasjonene kan endres uten varsel.
