Four strategically positioned pivot points and two linkages work together to create a single floating pivot point for the most active, efficient suspension system.
Anthem Advanced Pro 29
This superlight composite XC flyer blends the most up-to-date Maestro suspension technology with the speed, control and stability of progressive 29er geometry. If XC racing is your game, this is your express route to the podium.
Compare Models |
|||||
Anthem Advanced Pro 29 0
|
Anthem Advanced Pro 29 0 Eagle
|
Anthem Advanced Pro 29 1
|
Anthem Advanced Pro 29 2
|
Anthem Advanced Pro 29 Frameset
|
|
|
Wheels
|
Giant XCR-0 29 Composite WheelSystem | Giant XCR-0 29 Composite WheelSystem | Giant XCR-1 29 Composite WheelSystem | Giant XCR-1 29 Composite WheelSystem | |
|---|---|---|---|---|---|
|
Shifters
|
Shimano XTR | SRAM XX1 Eagle | Shimano Deore XT , 1x12 I-spec EV | Shimano SLX | |
|
Crankset
|
Shimano XTR, 34t | SRAM XX1 Eagle DUB, 34t | Shimano Deore XT , 32t | Shimano SLX , 32t | |
|
Fork
|
Fox 32 Float SC Factory Live Valve, 100mm, FIT4 damper, Boost 15x110 Kabolt, tapered | Fox 32 Float SC Factory Live Valve, 100mm, FIT4 damper, Boost 15x110 Kabolt, tapered | Fox 32 Float SC Performance Elite Remote, 100mm, FIT4 damper, remote lockout, Boost 15x110 Kabolt, tapered | Fox 32 Float Rhythm, 100mm, GRIP damper, two-position GRIP remote push to unlock, Boost 15x110 Kabolt, tapered | |
|
Colors
|
Metallic Blue / Carbon / Black | Rainbow Black / Black | Metallic Navy / Carbon | Rainbow Silver / Black | Chameleon Saturn |
Highlights
Engineered with a superlight Advanced-grade carbon frame, including the front triangle and rear swingarm, this full-suspension 29er features 90mm of smooth rear suspension travel and 100mm up front. The proven Maestro rear suspension system includes a trunnion mount shock with a lower leverage ratio for efficient pedaling and braking performance. The linkage allows for shorter chainstays, which improves the bike’s climbing capabilities and overall agility. The Advanced Forged Composite upper rocker arm is lighter, stiffer and stronger than the previous aluminum version, and other updates include wider Boost hub spacing and an integrated Giant WheelSystem that gives you super strong and stiff wheels for confident, precise handling on XC terrain.
1
Maestro Suspension Technology
2
Advanced Composite Mainframe and Swingarm
High-performance grade raw carbon fiber and custom resin is used to produce this high-quality frame in Giant’s own composite factory. Handcrafted monocoque construction makes both the mainframe and rear swingarm extremely lightweight, stiff and compliant.
3
29-Specific XC Geometry
Updated “long and low” XC frame geometry is tailored for 29-inch wheels to optimize control, acceleration and stability.
4
Boost Technology
Wider hub spacing (110mm front/148mm rear) results in stiffer wheels for added control plus more tire clearance and an improved chainline for optimal drivetrain performance.
5
Advanced Forged Composite Upper Rocker Arm
A state-of-the-art, high-pressure molding process is used to produce complex shaped carbon-fiber components that are lighter, stiffer and stronger than similar aluminum components.
6
Trunnion Mount
New shock mount produces a lower leverage ratio for increased pedaling and braking efficiency, plus a lower center of gravity and shorter chainstays for improved handling, climbing and agility.
7
PowerCore
A massively oversized bottom-bracket/chainstay area features a fully integrated, 92mm wide bottom-bracket design. Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.
8
OverDrive
Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/2” lower and 1 1/8” upper) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
9
Giant WheelSystem
Engineered with proprietary Dynamic Balanced Lacing technology, Giant’s all-new XCR Composite WheelSystem delivers superior efficiency, pinpoint control and engineered durability.
Techs & Features
Advanced Composite Technology
Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.
Advanced Forged Composite Technology
A state-of-the-art high-pressure molding process is used to produce complex-shaped carbon fiber components that are lighter, stiffer and stronger than similar components made from aluminum. This technology is used in critical performance parts such as Maestro Suspension rocker links.
Maestro Suspension Technology
Four strategically positioned pivot points and two linkages all work together to create a single floating pivot for the most active, efficient and independent suspension system on the trail.
OverDrive
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Tubeless System
Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
