Professional-grade raw carbon material is woven in our own composite factory using our most advanced engineering and construction methods including Continuous Fiber Technology to add strength while reducing weight and Carbon Nanotube resin to improve impact resistance.
가파른 오르막길 위로 빠르게 질주할 때, 2차례 MTB 마라톤 월드 챔피언 Leo Páez와 같은 XC 프로 선수를 위한 최고의 선택입니다.
Key Performance Factors
가벼운 무게와 민첩성
프로 레벨 Advanced SL 카본 프레임은 GIANT가 생산한 것 중 가장 가벼운 오프로드 프레임입니다. 이는 열정적인 XC 레이서들에게 클라이밍, 가속, 그리고 스프린트 경쟁에서 필요한 어드밴티지를 제공할 것입니다.
뛰어난 효율성
프레임은 높은 무게 대비 가성 비율을 지니도록 설계되었으며, 이는 트레일 위에서 효율적인 페달링 파워와 정밀한 핸들링을 제공합니다.
커스텀 컴플라이언스
프레임은 각 사이즈에 따라 조정되었습니다. 각각의 카본 레이업 스케줄은 수직 컴플라이언스를 최적화하여 XC 지형 위에서 부드러운 라이딩 퀄리티를 제공합니다.
하이라이트
월드컵의 역사와 진보적인 프레임 디자인을 찾아볼 수 있는 XtC Advanced SL은 GIANT의 오프로드 바이크 중 가장 가벼운 무게를 자랑합니다. 섀시는 프로 레벨 Advanced SL 카본 복합소재를 활용하여 수공으로 제작되었으며, 빠르게 굴러가는 29인치 휠에 맞춰 지오메트리를 최적화하였습니다. 또한 모든 프레임은 각각의 프레임 사이즈에 맞춰 최적의 카본 복합소재 레이업 스케줄에 따라 조립하였습니다. 그 결과 매우 뛰어난 클라이밍 효율성을 제공하며, 뿌리와 바위 위를 따라 달리는 거친 코스 위에서도 부드러운 핸들링을 선보이고, 뜨거운 XC 열정을 위한 최상의 퍼포먼스를 발휘합니다.

ADVANCED SL COMPOSITE
OPTIMIZED TUBE SHAPING
Frameset features special tubing shapes designed to minimize weight, optimize stiffness, and improve the bike’s handling on XC terrain.
OVERDRIVE
Designed to provide precise front-end steering performance, this system’s oversized headset bearings (1 1/2” lower and 1 1/8”) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
INTERNAL CABLE ROUTING
Large cable ports and tool-free bottom bracket guide ensure easy cable installation while minimizing frame weight.
MEGADRIVE
A massive rectangular downtube and oversized toptube work in unison to provide superior front end lateral and torsional steering precision. The precisely engineered, rectangular shaped downtube yields unprecedented steering and pedaling stiffness.
POWERCORE
GIANT TUBELESS SYSTEM
Integrated Tubeless WheelSystem and tires delivers improved efficiency, comfort and control in the most user-friendly and reliable system.
BOOST TECHNOLOGY
Wider hub spacing (110mm front / 148mm rear) results in stiffer wheels for added control plus more tire clearance and an improved chainline for optimal drivetrain performance.
기술
Advanced SL Composite Technology
OverDrive
Tubeless System
사이즈 가이드 및 지오메트리
사이즈표는 참고용이며, GIANT 또는 Liv 대리점과 상담, 문의하여 정확한 사이즈를 확인하시기 바랍니다.
적용 가능한 범위는 국가마다 다를 수 있습니다.

-
- S
-
163 cm5’4”
172 cm5’8”
-
- M
-
171 cm5’7”
180 cm5’11”
-
- L
-
179 cm5’10”
188 cm6’2”


S | M | L | ||
---|---|---|---|---|
A | 시트 튜브 길이 (mm) (inch) | 38015 | 43117 | 47518.7 |
B | 시트 튜브 각도 (degrees) | 73.5° | 73.5° | 73.5° |
C | 탑튜브 길이 (mm) (inch) | 59523.4 | 61424.2 | 63525 |
D | 헤드 튜브 길이 (mm) (inch) | 953.7 | 953.7 | 1054.1 |
E | 헤드튜브 각도 (degrees) | 69.5° | 69.5° | 70.0° |
F | 포크 레이크 (mm) (inch) | 431.7 | 431.7 | 431.7 |
G | 트레일 (mm) (inch) | 94.93.7 | 94.93.7 | 94.93.7 |
H | 휠베이스 (mm) (inch) | 108742.8 | 110643.5 | 112844.4 |
I | 체인스테이 길이 (mm) (inch) | 42516.7 | 42516.7 | 42516.7 |
J | BB (mm) (inch) | 582.3 | 582.3 | 582.3 |
K | 스택 (mm) (inch) | 60423.8 | 60423.8 | 61324.1 |
L | 범위 (mm) (inch) | 41616.4 | 43517.1 | 45317.8 |
M | 스탠드 오버 (mm) (inch) | 73729 | 76430.1 | 79131.1 |
N | 핸들바 폭 (mm) (inch) | 76029.9 | 76029.9 | 76029.9 |
O | 스템 길이 (mm) (inch) | 602.4 | 702.8 | 803.1 |
P | 크랭크 길이 (mm) (inch) | 1706.7 | 1756.9 | 1756.9 |
Q | 휠사이즈 | 29" | 29" | 29" |
-
사이즈S, M, L
-
색상Chameleon Galaxy
-
프레임Advanced SL-Grade Composite, 12x148mm thru-axle
-
포크RockShox SID SL Select, 100mm, Charger 2 RL damper, 44mm offset, 15x110 Maxle Stealth, remote lockout
-
서스펜션N/A
-
핸들바Giant Contact SLR XC Flat, 760x35mm
-
GripsGiant XC Pro S:32mm, M:32mm, L:34mm, XL:34mm
-
스템Giant Contact SL XC 35 S:60mm, M:70mm, L:80mm, XL:90mm
-
싯포스트Giant Contact Switch dropper, Shimano remote S: 125mm travel / 30.9 x 395mm M: 125mm travel / 30.9 x 395mm L: 125mm travel / 30.9 x 395mm XL: 125mm travel / 30.9 x 395mm
-
안장Fi'zi:k Antares R5 with K:ium rails
-
페달N/A
-
변속기Shimano Deore XT M8100, 1x12
-
앞 변속기N/A
-
뒷 변속기Shimano Deore XT M8100
-
브레이크Shimano Deore XT BR-M8100, hydraulic, Shimano RT-66 rotors [F]180mm, [R]160mm
-
브레이크 레버Shimano Deore XT BL-M8100
-
스프라켓Shimano Deore XT M8100, 10x51
-
체인KMC X-12
-
크랭크 셋Praxis Girder Carbon Boost, 32t S:170mm, M:175mm, L:175mm, XL:175mm
-
BBShimano, press fit
-
림Giant XCR 1 29 Carbon WheelSystem
-
허브Giant XCR 1 29 Carbon WheelSystem
-
스포크Giant XCR 1 29 Carbon WheelSystem
-
타이어Maxxis Rekon Race 29x2.25, foldable, TLR, EXO, tubeless
-
추가 기능tubeless prepared, 2.25" max tire size, 38t max chainring size
-
무게자전거의 무게를 확인하는 가장 정확한 방법은 지역 대리점에서 측정하는 것입니다. 많은 브랜드가 가능한 가장 낮은 무게를 표시하려고 노력하지만 실제 무게는 크기, 마감재, 하드웨어 및 악세서리 여부에 따라 달라집니다. 모든 GIANT 자전거는 동급 최고의 무게와 주행 품질을 고려하여 설계되었습니다.
나열된 모든 사양은 사전 통보없이 변경 될 수 있습니다.
나열된 모든 사양은 사전 통보없이 변경 될 수 있습니다.
