This Performance-grade material features 6061 alloy with single-butted tubes to produce a strong, lightweight frameset.
Percorri strade sconnesse o sterrate con questa nuovissima all-rounder in alluminio. La forcella in carbonio permette di ottenere una guida fluida mentre il sistema flip chip consente di regolare la geometria del telaio per adattare il passo e la distanza degli pneumatici a seconda del tuo stile di guida.
Key Performance Factors
Maneggevolezza e stabilità
Il telaio è progettato con geometria endurance e foderi posteriori più corti per ottenere ottima maneggevolezza, agilità e controllo. Una reach più lunga, un attacco manubrio più corto e un drop inferiore del movimento centrale migliorano la stabilità su terreni accidentati.
Integrazione dei componenti
Il nuovo telaio è caratterizzato da foderi verticali più sottili e ribassati per assorbire gli urti e le vibrazioni della strada. Il manubrio e il reggisella D-Fuse funzionano come un unico sistema per aggiungere fluidità di guida senza sacrificare la rigidità in curva, negli sprint o in salita.
Versatilità
Un flip chip sul forcellino posteriore regola la geometria per ottenere maggiore maneggevolezza e accelerazione o migliore stabilità e velocità in base alle esigenze. L'impostazione lunga consente di montare pneumatici di diametro fino a 53mm. C'è anche la possibilità di montare un reggisella tondo da 30,9mm o un reggisella telescopico.
Aluxx Aluminum
Composite Fork
Advanced-grade composite fork with an OverDrive tapered steerer tube absorbs road shock and vibrations and allows added clearance for tires up to 53mm wide.
D-Fuse Technology
Proprietary D-shaped seatpost and handlebar work together to dampen vibrations and absorb road shock, resulting in a smooth, compliant ride quality.
OverDrive
Designed to boost front-end stiffness and steering for precise handling, this oversized steerer tube technology features oversized headset bearings (1 1/4” lower and 1 1/8” upper) and a tapered steerer tube to provide optimal steering stiffness.
Seatpost Adaptor
New frame design allows you to switch from the proprietary D-Fuse seatpost to a standard round 30.9mm seatpost. This enables riders to choose any type of seatpost, including a dropper seatpost, depending on riding style and terrain.
Disc-Brake Integration
The frame and fork are engineered specifically for disc brakes for reliable braking performance in all weather and road conditions.
Giant Tubeless System
Integrated Tubeless WheelSystem and tires delivers improved efficiency, comfort and control in the most user-friendly and reliable system.
PowerCore
A massively oversized bottom bracket/chainstay area features a fully integrated, 86mm wide bottom bracket design. Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.
Flip Chip Dropout
Allows riders to quickly adjust the geometry and rear-wheel tire clearance with eccentric, offset two-position hardware in the rear wheel dropouts.
Integrated Mounts
Frameset features six water bottle mounts: two on the down tube, two on the fork, plus one each on the top tube and seat tube. Also includes a special adaptor at the seatpost for mounting a rack and is compatible with third-party setups so it’s easy to customize with fenders and other accessories.
