This state-of-the-art aluminum material is made predominantly from 6011 alloy and delivers best-in-class strength-to-weight ratios. The frameset also features unique welding technologies for a high-performance ride quality.
Important statement on COVID-19. Learn more
The SyncDrive Pro motor gives the new Trance X E+ Pro 29 a massive 80Nm of torque and 360 percent tunable support, all controlled by the new Giant E-bike App. This gives you the freedom to ride trails the way you want to. You can choose full power to ease your pedaling effort or tune it less aggressively to get more of a workout. Featuring 140mm of smooth Maestro suspension travel in the rear, 150mm up front, and progressive frame geometry that’s designed for 29-inch wheels, this is a whole new way to tackle technical singletrack trails. The EnergyPak 625 battery is cleanly integrated into the downtube of the lightweight ALUXX SL frame.
SyncDrive Pro motor delivers 80Nm of torque and tunable support ratios up to 360 percent. Smart Assist technology creates smooth pedal assistance that engages instantly when human power is applied, giving you reliable performance on steep climbs and at low speeds.
Optimized Maestro suspension for 29-inch wheels with 140mm rear/ 150mm front travel to roll over rough terrain with balance and stability, giving you more momentum for technical climbs and the confidence to fly on fast, rugged singletrack descents.
Flip chip lets you change the headtube and seattube angles, along with the bottom bracket height, to fine-tune the handling. You can choose the low position (65.8/76.0 head/seattube angle and 30mm BB drop) for faster, open terrain or high (66.5/76.7 head/seattube angle and 20mm drop) for slower, tighter singletrack.
How far can I expect to ride on a single battery charge?
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
The new Trance X E+ Pro 29 gives you the freedom to ride trails the way you want to. You can choose full power to ease your pedaling effort or tune it less aggressively to get more of a workout. Featuring 140mm of smooth Maestro suspension travel in the rear, 150mm up front, and progressive frame geometry that’s designed for 29-inch wheels, this is a whole new way to tackle technical singletrack trails.
This state-of-the-art aluminum material is made predominantly from 6011 alloy and delivers best-in-class strength-to-weight ratios. The frameset also features unique welding technologies for a high-performance ride quality.
This innovative system combines electric power with human power to produce a smart, natural and powerful E-bike riding experience. It’s an integrated group of technologies that includes our RideControl control unit, EnergyPak battery systems and SyncDrive Pro motor.
Tuned to deliver a powerful, performance-oriented riding style for challenging trails and higher cadences, this motor delivers 80Nm of power output with superior torque and support ratios up to 360 percent. The motor engages instantly when power is applied to the pedals.
Four strategically positioned pivot points and two linkages all work together to create a single floating pivot for the most active, efficient and independent suspension system on the trail.
Flip-chip adjustability lets you switch between two settings depending on the terrain you are riding. You can select either 66.5 or 65.8-degree head angle and 76.7 or 76.0-degree seattube angle, resulting in either a 20mm or 30mm bottom bracket drop.
Handlebar-mounted control unit allows you to adjust the support mode and view the battery level. Ergonomic buttons are built for easy use in off-road riding conditions, and a minimalist design offers a clean, uncluttered handlebar layout.
Six smart sensors precisely measure the power being applied to the pedals so the motor can provide just the right amount of assistance to create a natural, powerful riding experience. This helps optimize energy efficiency for both the rider and the battery system.
RideControl Ergo can wirelessly connect with the Giant E-bike App so your smart phone can function as a display for ride data and system updates.
Integrated Tubeless WheelSystem and tire deliver improved efficiency, comfort and control in the most user-friendly and reliable system.
Our most advanced E-bike battery system is cleanly integrated within the downtube of the frame. Continuous communication between the battery and charger provides fast charging. Batteries can charge up to 80 percent in 2.2 hours.
SyncDrive Pro powered by Yamaha is designed for high-performance E-bike riding. Giant tuned the motor to make it more powerful, producing a performance-oriented riding style. The lightweight, compact SyncDrive Pro motor is used primarily on Giant’s high-performance models.
Hybrid Cycling Technology is a system that combines electric power with human power to produce a smart, natural and powerful E-bike riding experience. It’s an integrated group of technologies that includes our RideControl control unit, EnergyPak battery systems and SyncDrive motor.
For more information, check out the link below.
All SyncDrive motors have Smart Assist technology, which adjusts the support to match the rider’s needs. By using information from multiple sensors, both rider input and terrain feedback are used to determine the optimal amount of pedaling assistance. SyncDrive is the only e-bike system that utilizes both rider input and terrain feedback. It gives you a smooth, natural riding experience with ample power when you need it, while also conserving power when you don’t need as much.
Four strategically positioned pivot points and two linkages all work together to create a single floating pivot for the most active, efficient and independent suspension system on the trail.
This High-Performance level, state-of-the-art aluminum material is made predominantly from 6011 alloy and delivers best-in-class strength-to-weight ratios. These framesets also feature unique welding technologies for a high-performance ride quality.
Giant’s latest EnergyPak battery systems feature streamlined designs that are integrated with the E-bike for a sleek and modern profile. Giant E-bikes offer several different EnergyPak options including the EnergyPak Smart and EnergyPak. Each one is designed to optimize the E-bike experience for a specific style of riding.
RideControl Ergo takes your E-bike riding experience to new levels with optimized controls and a clean handlebar layout. The robust buttons are designed to use in all conditions with a comfortable feel and grip. The controls are thoughtfully designed with new LED lighting that shows your battery level and lets you switch between five support modes (Power, Sport, Active, Basic, Eco). It’s also compatible with the new RideDash EVO, an integrated display that mounts on the handlebar/stem area and shows important ride date such as speed, distance and navigation.
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
S | M | L | XL | ||
---|---|---|---|---|---|
LOW | HIGH | LOW | HIGH | LOW | HIGH | LOW | HIGH | ||
A | Seat Tube Length (mm) (inch) | 40015.7 | 42516.7 | 45017.7 | 47518.7 |
B | Seat Tube Angle (degrees) | 76.0° | 76.7° | 76.0° | 76.7° | 76.0° | 76.7° | 76.0° | 76.7° |
C | Top Tube Length (mm) (inch) | 57522.6 | 57522.6 | 60523.8 | 60523.8 | 63525 | 63525 | 66526.2 | 66526.2 |
D | Head Tube Length (mm) (inch) | 953.7 | 1003.9 | 1104.3 | 1204.7 |
E | Head Tube Angle (degrees) | 65.8° | 66.5° | 65.8° | 66.5° | 65.8° | 66.5° | 65.8° | 66.5° |
F | Fork Rake (mm) (inch) | 441.7 | 441.7 | 441.7 | 441.7 |
G | Trail (mm) (inch) | 123.44.8 | 118.14.6 | 123.44.8 | 118.14.6 | 123.44.8 | 118.14.6 | 123.44.8 | 118.14.6 |
H | Wheelbase (mm) (inch) | 120247.3 | 120547.4 | 123348.5 | 123648.7 | 126549.8 | 126849.9 | 129751.1 | 129951.1 |
I | Chain Stay Length (mm) (inch) | 47218.6 | 47218.6 | 47218.6 | 47218.6 | 47218.6 | 47218.6 | 47218.6 | 47218.6 |
J | Bottom Bracket Drop (mm) (inch) | 301.2 | 200.8 | 301.2 | 200.8 | 301.2 | 200.8 | 301.2 | 200.8 |
K | Stack (mm) (inch) | 60823.9 | 60223.7 | 61324.1 | 60723.9 | 62224.5 | 61624.3 | 63124.8 | 62524.6 |
L | Reach (mm) (inch) | 42316.7 | 43317 | 45217.8 | 46218.2 | 48018.9 | 48919.3 | 50820 | 51720.4 |
M | Stand Over Height (mm) (inch) | 74429.3 | 75329.6 | 74529.3 | 75429.7 | 75029.5 | 75929.9 | 76029.9 | 77030.3 |
N | Handlebar Width (mm) (inch) | 78030.7 | 78030.7 | 78030.7 | 78030.7 |
O | Stem Length (mm) (inch) | 401.6 | 401.6 | 401.6 | 401.6 |
P | Crank Length (mm) (inch) | 1606.3 | 1606.3 | 1656.5 | 1656.5 |
Q | Wheel Size | 29" | 29" | 29" | 29" |
