Roam 3

2019
Skip to compare section

A Roam mindennapos kalandokra lett tervezve. Vele követheted az utad, bárhová is visz.

Könnyen kezelhető egyenes kormánnyal, könnyű ALUXX alu vázzal, a Roam az országúti kerékpárok és mountain bike-ok előnyeit kombinálja. Az első teleszkóp kényelmet és irányíthatóságot nyújt. A gyorsan gördülő 28-as kerekek mind az aszfalton, mint a könnyebb terepen jól érzik magukat.

Key Performance Factors

Könnyű és agilis

Az ALUXX alu vázzal könnyen megmászhatod az emelkedőket és gyorsíthatsz.

Kényelem és stabilitás

Az egyenes kormány kényelmes, de mégis hatékony pozíciót nyújt, mellyel könnyen legyőzheted a nehezebb terepet is.

Integrált csomagtartó rögzítés

Első és hátsó csomagtartó rögzítési pontokkal rendelkezik, mellyel a napi vagy akár hosszabb túrákra szükséges felszerelést magaddal viheted.

Techs & Features

ALUXX Aluminum Technology

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XS
      155 cm5’1” to 165 cm5’5”
  • S
      160 cm5’3” to 170 cm5’7”
  • M
      170 cm5’7” to 180 cm5’11”
  • L
      180 cm5’11” to 190 cm6’3”
  • XL
      190 cm6’3” to 200 cm6’7”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
 XSSMLXL
A Seat Tube Length (mm) (inch)39015.442016.546018.151020.155021.7
B Seat Tube Angle (degrees)73.0°73.0°73.0°73.0°73.0°
C Top Tube Length (mm) (inch)58022.859023.260023.66102462024.4
D Head Tube Length (mm) (inch)953.71154.51305.11455.71606.3
E Head Tube Angle (degrees)70.5°70.5°70.5°70.5°70.5°
F Fork Rake (mm) (inch)451.8451.8451.8451.8451.8
G Trail (mm) (inch)783.1783.1783.1783.1783.1
H Wheelbase (mm) (inch)108642.8109643.1110743.6111844112844.4
I Chain Stay Length (mm) (inch)45517.945517.945517.945517.945517.9
J Bottom Bracket Drop (mm) (inch)602.4602.4602.4602.4602.4
K Stack (mm) (inch)5582259623.561124.162524.663925.2
L Reach (mm) (inch)40315.940816.141316.341916.542516.7
M Stand Over Height (mm) (inch)70127.672728.675229.678130.780931.9
N Handlebar Width (mm) (inch)64025.264025.267026.467026.467026.4
O Stem Length (mm) (inch)803.1903.51003.91104.31104.3
P Crank Length (mm) (inch)1706.71706.7172.56.8172.56.81756.9
Q Wheel Size 700C700C700C700C700C
Specs
  • Sizes
    S, M, L, XL
  • Colors
    Metallic Black / Pure Red / Charcoal
  • Frame
    ALUXX-Grade Aluminum
  • Fork
    SR/Suntour NEX HLO 700C, 63mm
  • Shock
    N/A
  • Handlebar
    Giant Sport XC, 31.8
  • Stem
    Giant Sport
  • Seatpost
    Giant Sport, 27.2x375
  • Saddle
    Giant Connect (upright)
  • Pedals
    N/A
  • Shifters
    Shimano EF500 3x8
  • Front Derailleur
    Shimano Tourney
  • Rear Derailleur
    Shimano Acera RD-M360
  • Brakes
    MTB alloy linear pull
  • Brake Levers
    Shimano EF500
  • Cassette
    Shimano CS-HG31, 11x34
  • Chain
    KMC Z7
  • Crankset
    forged alloy, 28/38/48
  • Bottom Bracket
    cartridge
  • Rims
    Giant GX02 wheelset
  • Hubs
    Giant GX02 wheelset
  • Spokes
    Giant GX02 wheelset
  • Tires
    Giant Crosscut, 700x38C 60 tpi/wire/anti-puncture
  • Extras
    DT X-Defender
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

The specifications, colors, and availability of the products can be subjects to alter without prior notification. For availability and prices, please contact the retailers in your city / country.

The specifications, colors, and availability of the products can be subjects to alter without prior notification. For availability and prices, please contact the retailers in your city / country.
