TCR Advanced Pro 1 Disc

2019

€3,499

What is my size?

Share
This unbeatable all-rounder is lightweight, ultra-efficient, and always in control. From the steepest climbs to the fastest descents—in all conditions and any weather—TCR Advanced Pro Disc takes it to the next level.

The TCR Advanced Pro Disc gives you the lightweight performance to score the KOM plus the confidence to push your limits on technical descents. Engineered with an Advanced-grade composite frame featuring flat-mount disc-brake integration front and rear, it’s a versatile race machine for all types of road conditions. With its proven Compact Road geometry and OverDrive 2 front end, it has the best stiffness-to-weight ratio of any road bike in its class. Add in the efficiency and compliance of its Variant seatpost, and you get race-tuned road performance that can’t be beat.

Key Performance Factors

Pro-level race efficiency

With the highest pedaling stiffness-to-weight ratio of any bike in its class, this frameset is engineered to give Giant pro road racers superior climbing efficiency, sprint stiffness and all-rounder capabilities.

Total control

Integrated disc brakes deliver smooth, powerful stopping power and modulation for added control in variable weather and road conditions. Flat mounts and thru-axles boost stiffness and improve overall handling.

Speed and compliance

The Variant composite seatpost and Giant WheelSystem with tubeless tyres combine for a smooth ride and low rolling resistance.

Specs
  • Sizes
    S, M, M/L, L, XL
  • Colours
    Matte Glacier Silver / Matte Metallic Black / Matte Neon Red
  • Frame
    Advanced-Grade Composite
  • Fork
    Advanced-Grade Composite, full composite OverDrive 2 steerer
  • Shock
    N/A
  • Handlebar
    Giant Contact SL
  • Stem
    Giant Contact SL
  • Seatpost
    Giant Variant, composite
  • Saddle
    Giant Contact SL (forward)
  • Pedals
    N/A
  • Shifters
    Shimano Ultegra
  • Front Derailleur
    Shimano Ultegra
  • Rear Derailleur
    Shimano Ultegra
  • Brakes
    Shimano Ultegra, hydraulic
  • Brake Levers
    Shimano Ultegra, hydraulic
  • Cassette
    Shimano Ultegra, 11x30
  • Chain
    KMC X11SL-1
  • Crankset
    Shimano Ultegra or Praxis Zayante Carbon, 36/52
  • Bottom Bracket
    Shimano Press Fit
  • Rims
    Giant SLR-1 Disc WheelSystem (F:42mm, R:42mm)
  • Hubs
    Giant SLR-1 Disc WheelSystem, 12mm thru-axle, Center Lock
  • Spokes
    Giant SLR-1 Disc WheelSystem
  • Tyres
    Giant Gavia AC 1 tubeless 25mm
  • Extras
    RideSense Bluetooth
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

All specifications listed are subject to change without notice.

Highlights

The TCR Advanced Pro Disc gives you the lightweight performance to score the KOM plus the confidence to push your limits on technical descents. Engineered with an Advanced-grade composite frame featuring flat-mount disc-brake integration front and rear, it’s a versatile race machine for all types of road conditions. With its proven Compact Road geometry and OverDrive 2 front end, it has the best stiffness-to-weight ratio of any road bike in its class. Add in the efficiency and compliance of its Variant seatpost, and you get race-tuned road performance that can’t be beat.

2019 TCR Advanced Pro Disc with interactive tooltips

Geometry

bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  SMMLLXL
ASeat Tube Length (mm) (inch)44517.547018.550019.752520.755021.7
BSeat Tube Angle (degrees)73.5°73.0°73.0°73.0°72.0°
CTop Tube Length (mm) (inch)53521.155021.757022.458022.860523.8
DHead Tube Length (mm) (inch)1335.21485.81686.61887.42038
EHead Tube Angle (degrees)72.5°73.0°73.0°73.0°73.0°
FFork Rake (mm) (inch)451.8451.8451.8451.8451.8
GTrail (mm) (inch)602.4572.2572.2572.2572.2
HWheelbase (mm) (inch)97038.297638.499739.3100739.6102140.2
IChain Stay Length (mm) (inch)40515.940515.940515.940515.940515.9
JBottom Bracket Drop (mm) (inch)682.7682.7652.6652.6652.6
KStack (mm) (inch)52920.854521.556222.158122.959523.4
LReach (mm) (inch)37814.938315.139815.740215.841216.2
MStand Over Height (mm) (inch)74229.276530.17873180531.782332.4
NHandlebar Width (mm) (inch)40015.742016.542016.544017.344017.3
OStem Length (mm) (inch)903.51003.91104.31104.31204.7
PCrank Length (mm) (inch)1706.7172.56.8172.56.81756.91756.9
QWheel Size 700C700C700C700C700C

Technologies & Features

Advanced Composite Technology
Compact Road Design
OverDrive 2
RideSense
Tubeless System
