New

Stance E+ 1

2020

29.999,99 kn

Koja je moja veličina?

Podjelite

Steep climbs, technical descents, longer days on the trail. With a powerful SyncDrive Sport motor, this full-suspension E-bike gives you the power and technology to ride the trails you dream about.

Designed with trail-friendly geometry, Stance E+ helps beginner or intermediate trail riders experience off-road E-bike riding at its best. Its lightweight, strong and stiff ALUXX SL aluminum frame with FlexPoint suspension makes tricky singletrack trails easier to ride. It features 120mm of rear suspension travel and 130mm up front, plus the stable, nimble ride quality of 27.5+ wheels. The SyncDrive Sport motor delivers 350 percent tunable support ratios through the Giant E-bike App. The RideControl ONE integrated handlebar support buttons offer ergonomic control, and the EnergyPak 500Wh battery system lets you extend the ride. And now you can charge it up quickly with a new smart charger.

Ključni faktori

Strong motor support

The SyncDrive Sport motor with 70Nm of torque and 360 percent tunable support helps you climb steep, rugged trails with ease.

Total control

ALUXX SL aluminum frame with 120mm FlexPoint suspension and 27.5+ wheels produces a smooth, confident ride on technical trails. Giant E-bike App gives you navigation, health and fitness functions.

Efficient

500Wh EnergyPak offers the longest possible range. Integrated battery pack is easy to charge, up to 80% in just 60 minutes with new 6A Fast Charger.

Preuzmite PDF

VeličineXS, S, M, L, XL
BojeRainbow Black
OkvirALUXX SL-grade aluminum, 120mm FlexPoint suspension system
VilicaRockShox Recon RL, 130mm travel, Lockout, 110x15mm MaxleLite
AmortizerRockShox Monarch RT, High Volume, 184x44mm, custom tuned
VolanGiant Connect TR Riser 31.8x780mm
Lula volanaGiant Contact
Cijev sjedalaGiant Contact Switch, dropper, 30,9mm (S:100/M:125/L:150/XL:170)
SjedaloGiant Contact, Neutral
Pedale-
Ručice mjenjačaSRAM SX Eagle 12-speed
Prednji mjenjač-
Stražnji mjenjačSRAM SX Eagle 12-speed
KočniceShimano MT420, 4-piston brakes, 203mm
Ručice kočnicaShimano MT401 Hydraulic Disc
KazetaSRAM PG-1210, 11-50T, 12-Speed
LanacSRAM SX Eagle PowerLock, 12-speed
PogonSRAM X-Sync Eagle 38T 104BCD chainring Forged Alloy minimal Q-factor, 38T Steel Direct Mount ring (XS/S:160, M/L:165, XL:170)
Osovina pogona (BB)N/A
ObručiGiant AM 27.5+, Tubeless ready, 35mm inner width
NabeGiant eTracker Sport, [F] 15mm Thru-Axle [R] 141mm QR
ŽbiceStainless Steel
GumeMaxxis Rekon 27.5x2.6", Exo protect, Tubeless Ready
DodaciGiant EnergyPak 6A Smart charger
MotorGiant SyncDrive Sport 250W
SenzoriGiant PedalPlus 6-sensor technology
PrikazGiant RideControl ONE
BaterijaGiant EnergyPak Smart 500, 36V 13.8Ah integrated Lithium-Ion
TežinaKoliko je težak ovaj bicikl? To je vrlo često i dobro pitanje. Ali, istina je, da zapravo nema pravog industrijskog standarda za definiranje težine bicikla te upravo zbog toga dolazi do raznih dezinformacija. Razlike postoje zbog različitih veličina okvira, materijala okvira, završne obrade i ostalih komponenti. Što je bicikl lakši to su ove razlike važnije. U GIANTu vjerujemo da je jedini ispravan način da saznate točnu težinu bicikla da ga izvažete kod vašeg prodavača bicikala.

Sve navedene specifikacije podložne su promjeni bez prethodne najave.

Vodič za određivanje veličine i geometrija

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.

XS   155 cm5’1”  to 165 cm5’5”
S   163 cm5’4”  to 172 cm5’8”
M   171 cm5’7”  to 180 cm5’11”
L   179 cm5’10”  to 188 cm6’2”
XL   187 cm6’2”  to 198 cm6’6”
bike diagram
  XSSMLXL
Dužina cijevi sjedala (mm) (inch)3801540616432174821950720
Kut cijevi sjedala (degrees)73,5°73,5°73,5°73,5°73,5°
Dužina gornje cijevi (mm) (inch)56522,258022,860023,662524,665025,6
Dužina prednje cijevi (mm) (inch)1003,91003,91104,31204,71355,3
Kut vilice (degrees)67,0°67,0°67,0°67,0°67,0°
Zakrivljenost vilice (offset) (mm) (inch)461,8461,8461,8461,8461,8
Staza (mm) (inch)106,94,2106,94,2106,94,2106,94,2106,94,2
Međuosovinski razmak kotača (mm) (inch)114745,2116245,7118346,6120947,6123648,7
Dužina od osovine pogona do osovine zadnjeg kotača (CS) (mm) (inch)46518,346518,346518,346518,346518,3
Položaj osovine pogona (mm) (inch)200,8200,8200,8200,8200,8
Vertikalna dužina od osovine pogona do glave okvira (stack) (mm) (inch)59023,259023,259923,660823,962224,5
Horizontalna dužina od osovine pogona do glave okvira (reach) (mm) (inch)39015,440515,942216,644417,546518,3
Prekoračna visina (mm) (inch)71528,173128,874629,477830,678130,7
Širina volana (mm) (inch)78030,778030,778030,778030,778030,7
Dužina lule volana (mm) (inch)502502602,4602,4702,8
Dužina poluge pedale (mm) (inch)1656,51656,51706,71706,71706,7
Veličina kotača 27.5+27.5+27.5+27.5+27.5+

Tehnologije

Sve navedene specifikacije podložne su promjeni bez prethodne najave.
