TCR Advanced SL
Frameset

23.999,99 kn

Podjelite

From high alpine roads to grueling classics races, this is the choice for ultralight weight, super-stiff pedaling transmission and aero efficiency. Re-engineered to climb, corner and descend with uncompromising all-rounder speed, the all-new TCR Advanced SL is the winning choice.

Whatever the race situation, the legendary TCR Advanced SL gives you an advantage. It’s built on the lightest road frameset ever produced by Giant and features new aero tube shaping in the headtube, downtube and fork for pure speed and efficiency. The Variant integrated seatpost design saves weight while also adding compliance for a smoother ride on rough roads. Proven Compact Road Design gives the TCR Advanced SL the perfect blend of razor-sharp handling and confident control, and a new aero-efficient Giant Contact SL composite handlebar and stem complete this race-winning package.

Ključni faktori

Class-leading efficiency

New cutting-edge composite materials, reengineered tubing shapes and advanced robotic layup techniques result is a livelier ride quality, explosive acceleration and improved climbing efficiency with outstanding torsional frame stiffness.

Advanced aerodynamics

This is where the TCR’s most quantifiable gains can be found compared to previous generation models. Every tube shape was analyzed, engineered and tested to create an overall structure with significantly lower drag at a wider range of yaw angles. The result is a TCR that’s faster than ever in sprints and solo situations.

Total control

From composite WheelSystems with greater crosswind stability to user-friendly tubeless tire setups, this new TCR delivers greater control in a wide variety of road conditions. An all-new composite fork boasts impressive torsional stiffness.

Istaknuto

With the same unbeatable stiffness-to-weight ratio of the race-winning machines that came before it, the latest TCR Advanced SL adds aero efficiency to its legendary all-rounder capabilities. Here’s a look at its key technologies.

TCR Advanced SL with interactive tooltips

Tehnologije

Advanced SL Composite Technology
Compact Road Design
Integrated Seatpost
OverDrive 2
PowerCore
RideSense Ready

Vodič za određivanje veličine i geometrija

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XS
      157 cm5’2”  to 169 cm5’7”
  • S
      165 cm5’5”  to 175 cm5’9”
  • M
      171 cm5’7”  to 181 cm5’11”
  • ML
      177 cm5’10”  to 187 cm6’2”
  • L
      183 cm6’0”  to 193 cm6’4”
  • XL
      189 cm6’2”  to 199 cm6’6”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  XSSMMLLXL
ADužina cijevi sjedala (mm) (inch)68026,87102874029,177030,380031,583032,7
BKut cijevi sjedala (degrees)74,5°74,0°73,5°73,0°73,0°72,5°
CDužina gornje cijevi (mm) (inch)52020,553521,155021,756522,258022,860023,6
DDužina prednje cijevi (mm) (inch)1204,71305,11455,71656,51857,32007,9
EKut vilice (degrees)71,0°72,3°73,0°73,0°73,0°73,0°
FZakrivljenost vilice (offset) (mm) (inch)451,8451,8451,8451,8451,8451,8
GStaza (mm) (inch)72,12,8642,559,22,359,22,359,22,359,22,3
HMeđuosovinski razmak kotača (mm) (inch)97638,497738,598038,699139100639,6102040,2
IDužina od osovine pogona do osovine zadnjeg kotača (CS) (mm) (inch)40515,940515,940515,940515,940515,940515,9
JPoložaj osovine pogona (mm) (inch)722,869,52,769,52,7672,6672,6672,6
KVertikalna dužina od osovine pogona do glave okvira (stack) (mm) (inch)51720,452820,854521,556222,158122,959623,5
LHorizontalna dužina od osovine pogona do glave okvira (reach) (mm) (inch)37614,838315,138815,339315,540215,841216,2
MPrekoračna visina (mm) (inch)70227,672228,474329,376930,379331,281332
NŠirina volana (mm) (inch)40015,740015,742016,542016,544017,344017,3
ODužina lule volana (mm) (inch)803,1903,51003,91104,31104,31204,7
PDužina poluge pedale (mm) (inch)1706,71706,7172,56,8172,56,81756,91756,9
QVeličina kotača 700C700C700C700C700C700C
Specifikacije
  • Veličine
    XS, S, M, ML, L, XL
  • Boje
    Astral Aura
  • Okvir
    Advanced SL-Grade Composite, integrated seatpost
  • Vilica
    Advanced SL-Grade Composite, full-composite OverDrive 2 steerer
  • Cijev sjedala
    integrated design
  • Težina
    Koliko je težak ovaj bicikl? To je vrlo često i dobro pitanje. Ali, istina je, da zapravo nema pravog industrijskog standarda za definiranje težine bicikla te upravo zbog toga dolazi do raznih dezinformacija. Razlike postoje zbog različitih veličina okvira, materijala okvira, završne obrade i ostalih komponenti. Što je bicikl lakši to su ove razlike važnije. U GIANTu vjerujemo da je jedini ispravan način da saznate točnu težinu bicikla da ga izvažete kod vašeg prodavača bicikala.

Sve navedene specifikacije podložne su promjeni bez prethodne najave.
