Four strategically positioned pivot points and two linkages all work together to create a single floating pivot for the most active, efficient and independent suspension system on
the trail.
Reign Advanced Pro 29
Go fast, get rowdy, nail new lines with total control. We took everything you love about the legendary Reign and re-imagined it for 29-inch wheels. It’s progressive, it’s confident, and it’s born to fly on aggressive enduro style terrain.
Compare Models |
|||
Reign Advanced Pro 29 0
64.999,99 kn
|
Reign Advanced Pro 29 1
39.999,99 kn
|
Reign Advanced Pro 29 2
32.999,99 kn
|
|
|
Kotači
|
Giant TRX-0 29 Composite WheelSystem | Giant TR-1 29 WheelSystem | Giant AM 29, tubeless ready sleeve-joint rim, 30mm inner width |
|---|---|---|---|
|
Ručice mjenjača
|
SRAM X01 Eagle | SRAM GX Eagle | SRAM NX Eagle |
|
Pogon
|
SRAM X01 Eagle DUB, 34t with MRP AMg V2 Carbon guide | TruVativ Descendent 6k, DUB, 32t with MRP AMg V2 alloy guide | TruVativ Descendent 6k DUB, 32t with MRP AMg CS guide |
|
Vilica
|
Fox 36 Float, GRIP2 damper, 15x110 Kabolt, tapered, 42mm offset | Fox 36 Float, GRIP2 damper, 15x110 Kabolt, 42mm offset | RockShox Lyrik Select, 160mm, Boost 15x110 Maxle Stealth, tapered, 42mm offset |
|
Boje
|
Chameleon Saturn | Charcoal | Metallic Blue |
Istaknuto
When it comes to building the ultimate enduro machine, we look to Giant Factory Off-Road Team riders who are out there pushing the limits of their bodies and bikes. This bike is for them—and for everyone else who loves to charge hard. We engineered the geometry of the Advanced composite frame and swingarm around larger diameter 29-inch wheels. That means shorter chainstays, a longer toptube, and just the right angles with the headtube (65 degrees) and seattube (76.8 degrees). Then we gave it an updated Maestro suspension system with 146mm of rear suspension. With a new trunnion mount shock and Advanced Forged Composite rocker arm, the rear suspension feels super plush, active and shreddable. Beyond that, the new Reign Advanced Pro 29 features everything you need in a pro-level enduro machine, including a cleanly routed dropper seatpost, the latest Giant WheelSystem with Boost hub spacing, and tubeless tires set up right out of the box.
1
Maestro Suspension Technology
2
Advanced Composite Main and Subframe
High-performance grade raw carbon fiber and custom resin are used to produce this custom frame in Giant’s own composite factory. Handcrafted monocoque construction makes it extremely lightweight, stiff and compliant.
3
Advanced Forged Composite Technology
A state-of-the-art high-pressure molding process is used to produce complex-shaped carbon fiber components that are lighter, stiffer and stronger than similar components made from aluminum. This technology is used in critical performance parts such as Maestro Suspension rocker links.
4
29-Specific Enduro Geometry
Updated “long and low” enduro-frame geometry with 65/76.8-degree headtube/seattube angles for aggressive handling is tailored for 29-inch wheels to optimize roll-over capabilities and high-speed momentum.
5
Boost Technology
Wider hub spacing (110mm front / 148mm rear) results in stiffer wheels for added control plus more tire clearance and an improved chainline for optimal drivetrain performance.
6
Trunnion Mount
New shock mount produces a lower leverage ratio for increased pedaling and braking efficiency, plus a lower center of gravity and shorter chainstays for improved handling, climbing and agility.
7
MegaDrive
A massive rectangular downtube and oversized toptube work in unison to provide superior front end lateral and torsional steering precision. The precisely engineered, rectangular shaped downtube yields unprecedented steering and pedaling stiffness.
8
PowerCore
A massively oversized bottom-bracket/chainstay area features a fully integrated, 92-millimeter wide bottom-bracket design. Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.
9
Overdrive
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
10
Giant Tubeless System
Integrated Tubeless WheelSystem and tires deliver improved efficiency, comfort and control in the most user-friendly and reliable system.
Tehnologije
Advanced Forged Composite Technology
A state-of-the-art high-pressure molding process is used to produce complex-shaped carbon fiber components that are lighter, stiffer and stronger than similar components made from aluminum. This technology is used in critical performance parts such as Maestro Suspension rocker links.
ALUXX SL Aluminum Technology
This High-Performance level, state-of-the-art aluminum material is made predominantly from 6011 alloy and delivers best-in-class strength-to-weight ratios. These framesets also feature unique welding technologies for a high-performance ride quality.
Maestro Suspension Technology
Four strategically positioned pivot points and two linkages all work together to create a single floating pivot for the most active, efficient and independent suspension system on the trail.
OverDrive
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Tubeless System
Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
