Reign Advanced E+ 1

£6,999

Similar Products

Best For: Enduro

Reign Advanced E+ 0

£8,499

Best For: Enduro

Reign Advanced E+ 2

£5,999

On most models

Within 30 days

Starting From £35

Range

How far can I expect to ride on a single battery charge?

The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tyre pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.

The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.

EnergyPak 560 / SyncDrive Pro3X 100Nm

  • Range
  • Extreme: 83 km 51 miles
  • Good: 101 km 62 miles
  • Ideal: 171 km 106 miles

Techs & Features

Advanced Composite Technology
Energypak 560
EnergyPak Plus 280
SyncDrive Pro 3X
E+ System
Maestro Suspension Technology
Tubeless System
RideControl Ergo 4

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
 SMLXL
 LOW | HIGHLOW | HIGHLOW | HIGHLOW | HIGH
B Seat Tube Angle (degrees)77.1° | 77.5° | 77.9°77.5° | 77.9°77.1° | 77.5° | 77.9°77.1° | 77.5° | 77.9°
C Top Tube Length (mm) (inch)57022.4 | 56922.4 | 56822.460123.7 | 60023.662524.6 | 62424.6 | 62324.565725.9 | 65625.8 | 65525.8
D Head Tube Length (mm) (inch)953.71054.11204.71355.3
E Head Tube Angle (degrees)63.1° | 63.5° | 63.9°63.5° | 63.9°63.1° | 63.5° | 63.9°63.1° | 63.5° | 63.9°
H Wheelbase (mm) (inch)122648.3 | 122648.3 | 122748.3126149.6 | 126149.6128750.7 | 128850.7 | 128850.7132352.1 | 132352.1 | 132452.1
I Chain Stay Length (mm) (inch)45017.7 | 45017.7 | 45017.745017.7 | 45017.745017.7 | 45017.7 | 45017.745017.7 | 45017.7 | 45017.7
K Stack (mm) (inch)64725.5 | 64525.4 | 64225.365425.7 | 65125.666926.3 | 66726.3 | 66526.268326.9 | 68026.8 | 67826.7
L Reach (mm) (inch)42616.8 | 43016.9 | 43517.146018.1 | 46518.347618.7 | 48018.9 | 48519.150519.9 | 51020.1 | 51420.2
P Crank Length (mm) (inch)1556.11556.11556.11556.1
Specs
  • Motor
    Giant SyncDrive Pro3X,100Nm,48V 800W max power, 400% max support ratio
  • Controller
    Giant RideControl Ergo 4
  • Display
    Giant RideControl Go Lux
  • Battery
    iant EnergyPak Smart 560X, 560Wh, 48V Giant EnergyPak Plus 280Wh range extender
  • Charger
    Giant EnergyPak 4A Charger, 48V
  • Sizes
    S, M, L, XL
  • Colours
    Gloss Mars Dust
  • Frame
    Advanced-grade composite frame, Advanced forged composite upper rocker, 170mm Maestro suspension system
  • Fork
    Fox Float 38 Performance Elite, 180mm, GripX2 damper, 4-way adjust, 110x15, Kabolt X
  • Shock
    Fox DHX Performance Elite, 205x65mm, LSC | LSR | Std Steel Spring custom tuned
  • Handlebar
    Giant Contact SL TR35, 35mm rise, 5-degree upsweep, 9-degree backsweep, 35x800mm
  • Grips
    Giant Tactal Pro-E, tapered, 135mm Ø28~30mm (S/M) 142mm Ø29~32mm (L/XL)
  • Stem
    Giant Contact SL 35, 40 mm
  • Seatpost
    Giant Contact Switch AT, 30.9 mm travel-adjust dropper post, XS & S: 110-140 mm, M & L: 140-170 mm
  • Saddle
    Giant Romero, neutral
  • Pedals
    PEDALS NOT SUPPLIED
  • Shifters
    SRAM Eagle 90 Transmission
  • Rear Derailleur
    SRAM 90 Eagle Transmission
  • Brakes
    TRP EVO Expert, hydraulic disc, 4-piston, 220mm rotors [F/R]
  • Brake Levers
    TRP EVO Expert
  • Cassette
    SRAM Eagle Transmission, 10x52, 12-speed
  • Chain
    SRAM Eagle Transmission, Flattop, PowerLink, 12-speed
  • Crankset
    Praxis e-HD forged crankarm set, Q-factor: 168mm, length: 155mm
  • Rims
    Giant e-TRA 2, Hookless, 30mm inner width, Wide Guard
  • Hubs
    Giant E-Drive 260Nm, 72t engagement, Boost, 15x110mm[F] 12x148mm[R], e-bike optimized
  • Spokes
    Sapim Race [F] E-Lite [R], e-bike optimized
  • Tyres
    Maxxis Assagai 29x2.5" foldable, EXO+ 3C MaxxGrip [F] Maxxis Minion DHR II 27.5x2.4" WT foldable, DoubleDown, 3C MaxxGrip [R]
  • Extras
    Aegis Tire Checker, BLE+ tire pressure monitoring system Tubeless kit (liquid, valves, levers, manual, tool)
  • Lighting
    Optional: Giant Recon series e-bike lights available and direct-connect compatible
  • Combined Maximum Load Limit
    156kg
  • Weight
    23.2kg

Every effort has been made to ensure accuracy throughout this website. However, Giant reserves the right to change bike specifications, features, prices and colours without prior notice.
