STAY SMOOTH, EVEN ON ROUGH RIDES. THIS ENDURANCE ROAD BIKE IS PURPOSE-BUILT FOR YOUR LONGEST, HARDEST RIDES.
This lightweight Advanced-grade composite frame features endurance geometry and engineered compliance for a smooth, high-performance ride. Its tube shapes are optimized to absorb road shocks and vibrations, yet they’re still stiff in ways that matter—for pedaling efficiency and precise, stable handling. It’s actually crafted with specific carbon layups to give it just the right feel. And integrated disc-brake technology, featuring flat mounts and 12mm thru-axles front and rear, gives you added control in all types of weather and road conditions.
This lightweight Advanced-grade composite frame features endurance geometry and engineered compliance for a smooth, high-performance ride. Its tube shapes are optimized to absorb road shocks and vibrations, yet they’re still stiff in ways that matter—for pedaling efficiency and precise, stable handling. It’s actually crafted with specific carbon layups to give it just the right feel. And integrated disc-brake technology, featuring flat mounts and 12mm thru-axles front and rear, gives you added control in all types of weather and road conditions.
Ce guide est fait à titre indicatif, merci de bien contrôler avec revendeur pour confirmer ces informations.
167 cm5’6” 173 cm5’8” 178 cm5’10” 183 cm6’0” 188 cm6’2” 193 cm6’4”
| XS | S | M | M/L | L | XL | ||
|---|---|---|---|---|---|---|---|
| A | Longueur de tube de selle (mm) (inch) | 41016,1 | 44517,5 | 48018,9 | 51520,3 | 53521,1 | 56522,2 |
| B | Angle de tube de selle (degrees) | 74,5° | 74,0° | 73,5° | 73,0° | 73,0° | 72,5° |
| C | Longueur du tube supérieur (mm) (inch) | 51020,1 | 53020,9 | 54521,5 | 56022 | 57522,6 | 59523,4 |
| D | Longueur du tube de direction (mm) (inch) | 1254,9 | 1455,7 | 1656,5 | 1907,5 | 2108,3 | 2309,1 |
| E | Angle du tube de direction (degrees) | 71,0° | 72,0° | 72,5° | 72,5° | 72,5° | 72,5° |
| F | Déport de fourche (mm) (inch) | 451,8 | 451,8 | 451,8 | 451,8 | 451,8 | 451,8 |
| G | Trail (mm) (inch) | 702,8 | 642,5 | 602,4 | 602,4 | 602,4 | 602,4 |
| H | Empattement (mm) (inch) | 98338,7 | 99039 | 99539,2 | 100739,6 | 102240,2 | 103740,8 |
| I | Longueur fourche de pédalier (mm) (inch) | 42016,5 | 42016,5 | 42016,5 | 42016,5 | 42016,5 | 42016,5 |
| J | Hauteur du boitier de pédalier (mm) (inch) | 702,8 | 702,8 | 702,8 | 652,6 | 652,6 | 652,6 |
| K | Stack (mm) (inch) | 52320,6 | 54621,5 | 56722,3 | 58623,1 | 60523,8 | 62424,6 |
| L | Reach (mm) (inch) | 36514,4 | 37314,7 | 37714,8 | 38115 | 39015,4 | 39815,7 |
| M | Hauteur en statique (mm) (inch) | 73729 | 75429,7 | 77730,6 | 79031,1 | 81332 | 83332,8 |
| N | Largeur de cintre (mm) (inch) | 40015,7 | 40015,7 | 42016,5 | 42016,5 | 44017,3 | 44017,3 |
| O | Longueur de potence (mm) (inch) | 803,1 | 903,5 | 1003,9 | 1104,3 | 1104,3 | 1204,7 |
| P | Longueur des manivelles (mm) (inch) | 1706,7 | 1706,7 | 172,56,8 | 172,56,8 | 1756,9 | 1756,9 |
| Q | Diamètre des roues | 700C | 700C | 700C | 700C | 700C | 700C |
Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.
Introduced by Giant with the professional Team ONCE in the 1990s, Compact Road revolutionized the look and feel of high-performance road bikes forever. A downward sloping toptube (from the headtube to the seattube) creates smaller front and rear triangles for a lighter, stiffer bike. It also makes it easier for riders of all sizes to have a perfect fit.
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
The proprietary “D” shaped composite seatpost damps vibration, resulting in a smooth, compliant ride.
