PVP 3.199 €
Has añadido
TCX Advanced Pro 2
a tu cesta de la compra
El cuadro de carbono grado-Advanced es un 17,5 % más ligero que el de la generación anterior y conserva la mejor rigidez de torsión/pedaleo de su clase.
La tecnología integrada de frenos de disco con flat mount y bujes de eje pasante, combinada con sistema de ruedas Giant Tubeless ready, brinda un control adicional en condiciones variables y todo tipo de clima.
La innovadora tija de sillín D-Fuse reduce los impactos y las vibraciones de la carretera, y también tienes la opción de montar una tija circular estándar de 30.9 o telescópica dependiendo de tu estilo de conducción y terreno.
The superlight composite frame is handcrafted with race-proven geometry and asymmetrical chainstays for optimal power transfer. The D-Fuse composite seatpost helps smooth out bumps and vibrations, and you also have the option to use a 30.9mm round standard or dropper seatpost. Other innovations include a lightweight composite WheelSystem and tubeless tires right out of the box. The flat-mount disc brakes and 12mm front and rear thru-axles deliver total control and fast cornering, sprinting and climbing in all conditions.
High-performance grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.
Finite Element Analysis (FEA) was used to create tube shapes that enhance the performance and ride quality for cyclocross racing including a flattened and smoothed toptube shape for easier shouldering.
The most advanced steerer tube technology in today’s Giant bikes. Designed to offer unprecedented front-end steering performance, the system’s oversized headset bearings (1 1/2” lower, 1 1/4” upper) and tapered steerer tube work in harmony to provide supreme steering stiffness.
Integrated ports and a tool-free bottom bracket guide in the frameset make cable installation easier. The internal routing saves weight and creates a cleaner look and performance.
All-new proprietary “D” shaped composite seatpost dampens vibration, resulting in a smooth, compliant ride.
New frame design allows you to switch from the proprietary D-Fuse seatpost to a standard round 30.9mm seatpost. This enables riders to choose any type of seatpost, including a dropper seatpost, depending on riding style and terrain.
Eliminates the outermost woven composite sheet (found on heavier framesets) to reduce weight without affecting ride quality, strength or stiffness.
The frame and fork are engineered with flat-mount disc-brake technology for powerful, consistent braking performance in all conditions. New front (12x100mm) and rear (12x142mm) thru-axles boost stiffness and steering precision.
A massively oversized bottom bracket area features a fully integrated 86mm wide design. Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.
Engineered with proprietary Dynamic Balanced Lacing, an all-new composite WheelSystem and tubeless tires deliver improved efficiency, comfort and control in the most user-friendly and reliable system.
La tecnología para tubo de dirección más avanzada de Giant hasta el momento. Diseñado para ofrecer una precisión de dirección sin parangón, el sistema de dirección sobredimensionado con rodamientos (1-1/2" abajo y 1-1/4" arriba) y el tubo de dirección cónico ofrecen una rigidez delantera superior.
Tallas solo para referencia. Comprueba con una tienda local Giant o Liv para determinar la talla adecuada. Las tallas pueden variar de un país a otro.
168 cm5’6” 174 cm5’9” 180 cm5’11” 186 cm6’1” 192 cm6’4” 198 cm6’6”
| XS | S | M | ML | L | XL | |
|---|---|---|---|---|---|---|
| A Longitud del tubo del sillín (mm) (inch) | 49019,3 | 50519,9 | 52520,7 | 54521,5 | 55521,9 | 56522,2 |
| B Ángulo del tubo del sillín (degrees) | 74,0° | 73,5° | 73,0° | 73,0° | 73,0° | 73,0° |
| C Longitud del tubo superior (mm) (mm) (inch) | 51520,3 | 53020,9 | 54521,5 | 56022 | 57522,6 | 59023,2 |
| D Longitud del tubo de dirección (mm) (mm) (inch) | 1184,6 | 1335,2 | 1485,8 | 1636,4 | 1787 | 1937,6 |
| E Ángulo del tubo de dirección (degrees) | 70,7° | 71,0° | 71,5° | 72,0° | 72,5° | 72,5° |
| F Inclinación de la horquilla (mm) (inch) | 502 | 502 | 502 | 502 | 502 | 502 |
| G Trail (mm) (mm) (inch) | 70,32,8 | 68,32,7 | 65,12,6 | 61,82,4 | 58,62,3 | 58,62,3 |
| H Distancia entre ejes (mm) (mm) (inch) | 100639,6 | 101439,9 | 102040,2 | 103040,6 | 104040,9 | 105541,5 |
| I Longitud de la vaina (mm) (mm) (inch) | 43016,9 | 43016,9 | 43016,9 | 43016,9 | 43016,9 | 43016,9 |
| J Caída del eje de pedalier (mm) (mm) (inch) | 602,4 | 602,4 | 602,4 | 602,4 | 602,4 | 602,4 |
| K Stack (mm) (mm) (inch) | 52520,7 | 54021,3 | 55621,9 | 57222,5 | 58923,2 | 60323,7 |
| L Reach (mm) (mm) (inch) | 36514,4 | 37014,6 | 37514,8 | 38515,2 | 39515,6 | 40616 |
| M Altura del suelo al tubo (mm) (mm) (inch) | 77530,5 | 78831 | 80731,8 | 82632,5 | 83232,8 | 84533,3 |
| N Ancho del manillar (mm) (mm) (inch) | 40015,7 | 40015,7 | 42016,5 | 42016,5 | 44017,3 | 44017,3 |
| O Longitud de la potencia (mm) (mm) (inch) | 702,8 | 803,1 | 903,5 | 1003,9 | 1003,9 | 1104,3 |
| P Longitud de las bielas (mm) (mm) (inch) | 1706,7 | 1706,7 | 172,56,8 | 172,56,8 | 1756,9 | 1756,9 |
| Q Tamaño de ruedas | 700C | 700C | 700C | 700C | 700C | 700C |
Giant se reserva el derecho a modificar especificaciones, precios o colores sin previo aviso.
