Starting at $1000

Award Winning Bikes

Unleash your full potential

Buying a bike online is as easy as 1-2-3!

Float through rock gardens, hit the jumps, and find the faster line. With quick-handling 27.5 wheels and adjustable frame geometry, this lively trail bike is a party on wheels.

Key Performance Factors

Adjustable frame geometry

New flip chip feature lets you change the headtube and seattube angles, as well as the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style.

27.5 agility and control

27.5-inch wheels balance agility and control, giving you the ability to roll over rugged terrain, flick the bike at speed, change lines, and explode out of corners.

Progressive suspension

Updated Maestro rear suspension features a trunnion mount shock with a longer stroke and smoother feel. With 145mm of rear travel (and 160mm up front), it has an Advanced Forged Composite upper rocker arm for increased stiffness and strength plus lower overall frame weight.

Highlights

Built for those who favor the responsive, agile handling of 27.5 wheels, Trance X features a flip chip that lets you adjust the frame geometry for riding style and terrain. You can choose a steeper or slacker head tube angle and either a 20mm or 30mm bottom bracket drop. The ALUXX SL aluminum frame has an updated Maestro rear suspension featuring 145mm of smooth, active rear travel. A trunnion-mount shock and Advanced Forged Composite rocker arm help soak up bumps, giving you traction and control to float through rocks, roots and ruts. Confidence is further bolstered by a 160mm travel suspension fork up front.

Trance X with interactive tooltips

Techs & Features

Advanced Forged Composite Technology
ALUXX SL Aluminum Technology
Maestro Suspension Technology
OverDrive
Tubeless System
Flip Chip - Maestro

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • S
      163 cm5’4”  to 172 cm5’8”
  • M
      171 cm5’7”  to 180 cm5’11”
  • L
      179 cm5’10”  to 188 cm6’2”
  • XL
      187 cm6’2”  to 196 cm6’5”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  SMLXL
  LOW | HIGHLOW | HIGHLOW | HIGHLOW | HIGH
ASeat Tube Length (mm) (inch)42016.543016.946518.349619.5
BSeat Tube Angle (degrees)77.2° | 78.0°76.3° | 77.0°76.3° | 77.0°76.3° | 77.0°
CTop Tube Length (mm) (inch)56222.1 | 5602259523.4 | 59323.362224.5 | 62024.464925.6 | 64725.5
DHead Tube Length (mm) (inch)953.71054.11154.51254.9
EHead Tube Angle (degrees)63.7° | 64.5°63.8° | 64.5°63.8° | 64.5°63.8° | 64.5°
FFork Rake (mm) (inch)371.5371.5371.5371.5
GTrail (mm) (inch)1385.4 | 1325.21385.4 | 1325.21385.4 | 1325.21385.4 | 1325.2
HWheelbase (mm) (inch)117946.4 | 117746.3120347.4 | 120247.3123348.5 | 123148.5126249.7 | 126049.6
IChain Stay Length (mm) (inch)43317 | 43016.943317 | 43016.943317 | 43016.943317 | 43016.9
JBottom Bracket Drop (mm) (inch)301.2 | 200.8301.2 | 200.8301.2 | 200.8301.2 | 200.8
KStack (mm) (inch)59623.5 | 59023.260523.8 | 59923.661424.2 | 60823.962324.5 | 61724.3
LReach (mm) (inch)42716.8 | 43517.144717.6 | 45517.947218.6 | 48018.949719.6 | 50519.9
MStand Over Height (mm) (inch)70927.9 | 71828.371428.1 | 72328.574029.1 | 75029.576230 | 77230.4
NHandlebar Width (mm) (inch)80031.580031.580031.580031.5
OStem Length (mm) (inch)401.6401.6502502
PCrank Length (mm) (inch)1656.51706.71706.71706.7
QWheel Size 27,5"27,5"27,5"27,5"
Specs
  • Sizes
    S, M, L, XL
  • Colours
    Black / Smoke Metal / Chrome
  • Frame
    ALUXX SL-Grade Aluminum front and rear triangles, 145mm Maestro suspension, flip chip, 12x148mm thru-axle
  • Fork
    Fox 36 Performance Elite, GRIP 2 damper, 37mm offset, 160mm, 15x110 Kabolt X, custom tuned for Giant
  • Shock
    Fox Float X Performance Elite, lockout, 185/55, custom tuned for Giant
  • Handlebar
    Giant Contact TR35, 800x35mm, 20mm rise
  • Grips
    Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm
  • Stem
    Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
  • Seatpost
    TranzX travel-adjustable dropper, remote S: 120-150mm travel / 30.9 x 459mm M: 140-170mm travel / 30.9 x 499mm L: 170-200mm travel / 30.9 x 525mm XL: 170-200mm travel / 30.9 x 525mm
  • Saddle
    Giant Romero
  • Pedals
    N/A
  • Shifters
    SRAM GX Eagle, 1x12
  • Front Derailleur
    N/A
  • Rear Derailleur
    SRAM GX Eagle
  • Brakes
    SRAM Code R, hydraulic, SRAM CenterLine rotors [F]200mm, [R]180mm
  • Brake Levers
    SRAM Code
  • Cassette
    SRAM XG-1275, 10x52
  • Chain
    SRAM GX Eagle
  • Crankset
    SRAM GX Eagle, 32t S:165mm, M:170mm, L:170mm, XL:170mm
  • Bottom Bracket
    SRAM DUB, press fit
  • Rims
    Giant TR-1 27.5 WheelSystem
  • Hubs
    Giant TR-1 27.5 WheelSystem
  • Spokes
    Giant TR-1 27.5 WheelSystem
  • Tires
    [F] Maxxis Assegai 27.5x2.6, 3C MaxxTerra, EXO, TR [R] Maxxis Minion DHRII 27.5x2.6, 3C MaxxTerra, EXO, TR, tubeless
  • Extras
    tubeless prepared, 2.6" max tire size, 34t max chainring size, MRP AMG CS chain guide
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
